Multi-point thermistor

Multi point thermistor is an instrument used to measure temperature gradients in containers or storage tanks on production sites, which requires simultaneous temperature measurement at multiple locations. As a temperature sensor, multi-point thermistor is usually connected to multi-channel display regulators, recorders, or PLC systems to measure and display the temperature at different gradient points.

1、 Main technical parameters:

（1） Electrical export: M20*1.5   NPT1/2

（2） Thermal response time: ＜ 30S

（3）Wire diameter: Ф3 Ф4 Ф5 Ф6

（4）Protection level: IP65

（5）Output format: Pt100 signal output 4-20mA output signal

（6）Temperature measurement range:- 200~500℃

（7） Accuracy level: Class A, Class B

（8）Connection type: threaded flange

2、 Characteristics

（1）Multi point measurement, multi-point signal output, displaying temperature separately

（2）Multi point thermistor adopts armored thermistor elements, which are easy to bend

（3） Fast thermal response time

（4）Long service life

3、 Selection Notice

The purchaser shall provide detailed on-site conditions

The location requirements for the measurement points should be provided

points

Installation size

remarks:

1. The material of multi-point thermistor is determined according to the measured medium or customer requirements

2. Multi point thermal resistance external protection tube is available for customers to provide or order through agreement
